2-20
Outboard Rigging Guide - 2001 Jet Drive Eng. Mtg., Maintenance,
Shift Cable Instruction, Service Info.
40 and 50 Models (Cont’d.)
REF
NO. DESCRIPTION QTY.
1 Jet Drive Assembly
2 Main Housing 1
3 Reverse Gate 1
4 Pivot Pin, Reverse Gate 2
5 Nylon Sleeve, Reverse Gate Pivot Pin 2
6 Bolt, Reverse Gate Fixing 2
7 Hose, Grease Exit 1
8 Fitting, Grease 1
9 Nut Assembly, Exhaust Tube 2
10 Dowel Pin, 3/16" x 1/2" 2
11 Shift Cam 1
12* Bolt 1
13* Rod End 1
14* Shifter Bushing (not used '95 and later) 1
15* Nut, Fiber Lock (1/4-20) 1
16* Flat Washer (not used '95 and later) 1
17 Cam Eccentric Drilled 1
18 Bracket, Cable Support 1
19 Bolt, Bracket 1/4-20 x 5/8" 2
20 Flat Washer 1/4" 2
21 Clamp, Cable 1
22 Plate, Backing, Cable Clamp 1
23 Bolt, Cable Clamp 2
24 Locknut 2
25 Adapter Plate 1
26 Dowel Pin, 6mm x 16mm 2
27 O-Ring 1
28 Bolt, Adapter Plate 10 x 35mm 4
29 Bolt, Adapter Plate 3/8-16 x 1/4" 1
30 Lock Washer M10 5
31 Intake Housing 1
32 Intake Grille 1
33 Bolt, Intake Housing 6
34 Driveshaft 1
35 Special Key, Driveshaft 1
36 Thrust Ring, Shaft Bearing 1
37 Nylon Sleeve, Impeller Bore 1
38 Special Key, Impeller 1
39 Impeller 1
40 Shim, Impeller Adjustment 9
41 Tab Lock 1
42 Locknut 1
43 Seal, Shaft Outer 2
44 Retaining Ring, Inner and Outer Seal 4
45 Seal, Shaft Inner 2
REF
NO. DESCRIPTION QTY.
46 Bearing and Seal Housing 1
47 Machine Screw, Housing 10-24 x 5/8" 2
48 Lock Washer #10 5
49 Bearing 1
50 Thrust Washer 1
51 Collar 1
52 Backup Washer 1
53 Upper Seal Carrier 1
54 O-Ring 2
55 Retaining Ring 5
56 Brass Extension Tube 1
57 Dowel Pin 2
58 Gasket 1
59 Steel Plate 1
60 Gasket 1
61 Impeller, Water Pump 1
62 Cartridge 1
63 Housing, Water Pump 1
64 Bolt, Short, Housing 5/16-18 x 2-1/4" 2
65 Bolt, Long, Housing and Adapter
Plate 5 /16-18 x 2-3/4" 6
66 Lock Washer 5/16" 9
67 Bolt, Adapter Plate 8 x 30mm 1
68 Shaft Roller 1
69 Roller Assembly 1
70 Washer 1
71 Nut, Nylon 2
72 Gate Bumper 1
73 Gate Assembly 1
74 Exhaust Tube 1
75 Screw, Flush 1
76 Washer, Flush 1
77* Nut, Jam (not used '95 and later) 1
78 Washer, Spring (not used '95 and later) 1
79 Nut, Hex (not used '95 and later) 1
80 Cam Bushing 1
81 Cam Washer 1
82 Cam Shim 1
83 Spring, Cam bumper 1
84 U-Bolt 1
85 Screw 1
86 Spring, Gate Pivot 1
87 Circlip 1
88 O-Ring ('95 and later) 3
*Not used on pre '95 40MJH
