Yamaha F80B - Upper Case

6D93G11
7-6
1
2
3
4
5
6
7
8
9
Upper case
7
No. Part name Q’ty Remarks
1 Oil seal 1
Not reusable
2Bolt 6 M6
×
45 mm
3 Oil pump assembly 1
4 Dowel 2
5O-ring 2
Not reusable
6 Upper case assembly 1
7 Cover 2
8 Bolt 4 M10
×
40 mm
9Grommet 1
10 Grommet 1
11 Nut 2
12 Nut 2
13 Washer 2
14 Washer 2
15 Grease nipple 1
16 Bolt 1 M8
×
16 mm
17 Ground lead 1
S6D87030
3
5
4
4
11
12
13
14
15
16
17
6
7
8
5
LT
LT
572
T
R
.
.
10 N
·
m (1.0 kgf
·
m, 7.4 ft
·
Ib)
T
R
.
.
3 N
·
m (0.3 kgf
·
m, 2.2 ft
·
Ib)
LT
572
LT
T
R
.
.
51 N
·
m (5.1 kgf
·
m, 37.6 ft
·
Ib)
10
9
2
1
AA
AA
Bottom cowling / Upper case
