Yamaha F80B - Timing Belt and Sprockets

6D93G11
5-6
1
2
3
4
5
6
7
8
9
5
No. Part name Q’ty Remarks
1 Timing belt 1
2 Bolt 2 M10
×
35 mm
3 Dowel 2
4 Driven sprocket 2
5Bolt 2 M6
×
15 mm
6Bracket 1
7 Bolt 1 M10
×
45 mm
8 Timing belt tensioner 1
9Spring 1
10 Plastic tie 1
Not reusable
11 Hose 1
12 Clamp 1
13 Nut 1
14 Drive sprocket 1
15 Plate 1
16 Woodruff key 1
S6D85030
67F-46241-00
11
12
10
14
15
R
.
.
265 N
·
m (26.5 kgf
·
m, 195.5 ft
·
lb)
8
16
7
6
1
2
5
3
4
E
E
R
.
.
60 N
·
m (6.0 kgf
·
m, 44.3 ft
·
Ib)
13
R
.
.
39 N
·
m (3.9 kgf
·
m, 28.8 ft
·
Ib)
E
9
Power unit
