Yamaha F80B - Page 78

POWR
Power unit
5-9
6D93G11
5
No. Part name Q’ty Remarks
1 Oil filler cap 1
2O-ring 1
3 Cylinder head cover 1
4Screw 8 ø4
×
8 mm
5Plate 1
6Grommet 2
7Gasket 1
Not reusable
8Bolt 14 M6
×
30 mm
9Camshaft cap 2
10 Camshaft cap 8
11 Bolt 4 M7
×
48 mm
12 Bolt 16 M7
×
37 mm
13 Oil seal 2
Not reusable
14 Camshaft 2
S6D85070
S1280B
S1280B
4
3
8
7
1
2
5
6
11
10
12
14
9
9
13
13
10
10
10
LT
271
E
E
E
E
E
E
E
E
M
T
R
.
.
2 N
·
m (0.2 kgf
·
m, 1.5 ft
·
Ib)
T
R
.
.
1 8 N
•
m (0.8 kgf
•
m, 5.9 ft
•
lb)
2 17 N
•
m (1.7 kgf
•
m, 12.5 ft
•
lb)
T
R
.
.
1 8 N
•
m (0.8 kgf
•
m, 5.9 ft
•
lb)
2 17 N
•
m (1.7 kgf
•
m, 12.5 ft
•
lb)
T
R
.
.
1 8 N
·
m (0.8 kgf
·
m, 5.9 ft
·
lb)
2 8 N
·
m (0.8 kgf
·
m, 5.9 ft
·
lb)
