3 - 4
CHK
ADJ
SEATS AND FUEL TANK
EAS00039
SEATS AND FUEL TANK
SEATS
Order Job/Part Q’ty Remarks
Removing the seats
Remove the parts in the order listed.
1 Rider seat 1
2 Passenger seat 1
For installation, reverse the removal
procedure.
