4 - 11

CHAS

REAR WHEEL AND BRAKE DISC

EEAS00562

REMOVING THE REAR WHEEL

1. Stand the motorcycle on a level surface.

WARNING

Securely support the motorcycle so that

there is no danger of it falling over.

NOTE:

Place the motorcycle on a suitable stand so

that the rear wheel is elevated.

2. Remove:

• brake caliper bracket

NOTE:

Do not depress the brake pedal when remov-

ing the brake caliper bracket with brake cali-

per.

3. Remove:

• rear wheel

NOTE:

Move the rear wheel to the right to separate it

from the final drive housing.

EAS00565

CHECKING THE REAR WHEEL

1. Check:

• wheel axle

• rear wheel

• wheel bearings

• oil seals

Refer to “FRONT WHEEL AND BRAKE

DISCS”.

2. Check:

• tire

• rear wheel

Damage/wear

→

Replace.

Refer to “CHECKING THE TIRES” and

“CHECKING THE WHEELS” in chapter 3.
