4-12
CHAS
REAR WHEEL
Removing the rear brake disc and rear wheel sprocket
Order Job/Parts to remove Q’ty Remarks
1 Rear wheel sprocket 1
2 Rear wheel drive hub 1
3 Rear wheel drive hub damper 6
4 Rear brake disc 1
5 Rear wheel sensor rotor 1
6Oil seal 1
7 Bearing 1
8Spacer 1
9Oil seal 1
10 Bearing 1
11 Collar 1
For installation, reverse the removal proce-
dure.
43 N·m (4.3 kgf·m, 32 lb·ft)
8.0 N·m (0.8 kgf·m, 5.9 lb·ft)
23 N·m (2.3 kgf·m, 17 lb·ft)
