Yamaha FZ 25 2021 - Chassis Maintenance Specifications

2-6
SPEC
MAINTENANCE SPECIFICATION (CHASSIS)
MAINTENANCE SPECIFICATION (CHASSIS)
Chassis
Frame type Diamond
Caster angle 24.5 °
Trail 98 mm (3.9 in)
Front wheel
Wheel type Cast wheel
Rim size 17M/C  MT2.50
Radial wheel runout limit 1.0 mm (0.04 in)
Lateral wheel runout limit 0.5 mm (0.02 in)
Wheel axle bending limit 0.25 mm (0.01 in)
Rear wheel
Wheel type Cast wheel
Rim size 17M/C  MT4.00
Radial wheel runout limit 1.0 mm (0.04 in)
Lateral wheel runout limit 0.5 mm (0.02 in)
Wheel axle bending limit 0.25 mm (0.01 in)
Front tire
Type Tubeless
Size 100/80-17M/C 52P
Manufacturer/model MRF/NYLOGRIP ZAPPER-FX1
Rear tire
Type Tubeless
Size 140/70-17M/C 66S
Manufacturer/model MRF/NYLOGRIP ZAPPER-S2
Tire air pressure (measured on cold tires)
Front 175 kPa (1.75 kgf/cm
2
, 25 psi, 1.75 bar)
Rear 200 kPa (2.00 kgf/cm
2
, 29 psi, 2.00 bar)
Front brake
Type Hydraulic single disc brake
Disc outside diameter  thickness 282.0  4.0 mm (11.10  0.16 in)
Brake disc thickness limit 3.5 mm (0.14 in)
Brake disc runout limit (as measured on wheel) 0.15 mm (0.0059 in)
Brake pad lining thickness 4.3 mm (0.17 in)
Limit 0.6 mm (0.02 in)
Master cylinder inside diameter 12.70 mm (0.50 in)
Caliper cylinder inside diameter (Right) 28.00 mm, 28.00 mm (1.10 in, 1.10 in)
Specified brake fluid DOT 4
