MAINTENANCE SPECIFICATION (ELECTRICAL)
MAINTENANCE SPECIFICATION (ELECTRICAL)
Voltage
System voltage 12 V
Ignition system
Ignition system TCI
Ignition timing (B.T.D.C.) 8.0°–12.0°/1400 r/min
High altitude ignition timing (B.T.D.C.) 19.9°/1400 r/min
Engine control unit
Model TBDF4E
Ignition coil
Primary coil resistance 2.34–2.86
Secondary coil resistance 9.45–11.55 k
Spark plug cap
Resistance 3.75–6.25 k
Lean angle sensor output voltage
Operating angle 50°
Output voltage up to operating angle 0.4–1.4 V
Output voltage over operating angle 3.7–4.4 V
Charging system
Charging system AC magneto
Standard output 14.0 V, 11.5 A at 5000 r/min
Stator coil resistance 0.456–0.684
Rectifier/regulator
Regulator type Single-phase
Regulated voltage (DC) 14–14.8 V
Battery
Model ETZ-7
Voltage, capacity 12 V, 6.0 Ah (10 HR)
Bulb, wattage
Headlight LED
Brake/tail light LED
Front turn signal light 10.0 W
Rear turn signal light 10.0 W
Auxiliary light LED
License plate light 5.0 W
Meter lighting LED
Indicator light
Neutral indicator light LED
High beam indicator light LED
Turn signal indicator light LED
Engine trouble warning light LED
ABS warning light LED
