SPEC
MAINTENANCE SPECIFICATION (ELECTRICAL)
Starter motor
Brush overall length 10.0 mm (0.39 in)
Limit 3.50 mm (0.14 in)
Brush spring force 5.52–8.28 N (563–844 gf, 19.87–29.80 oz)
Mica undercut (depth) 1.50 mm (0.06 in)
Fuel sender unit
Sender unit resistance (full) 10.0–14.0 
Sender unit resistance (empty) 267.0–273.0 
Fuel injection sensor
Crankshaft position sensor resistance 192–288 
Intake air temperature sensor resistance 5700–6300  at
0 °C (5700 – 6300  at 32 °F)
Atmospheric pressure sensor output voltage 3.88–4.12 V at 101.3 kPa (3.88–4.12 V at 1.01
kgf/cm
2
, 3.88–4.12 V at 14.7 psi)
Engine temperature sensor resistance
28500 – 31500  at 0 °C (28500 – 31500  at 32 °F)
1819–2223  at 75 ° C (1819–2223  at 167 ° F)
Fuse(s)
Main fuse 15.0 A
ABS control unit fuse 2.0 A
ABS motor fuse 30.0 A
ABS solenoid fuse 15.0 A
