6-72
–+
ELEC
ABS (ANTI-LOCK BRAKE SYSTEM)
5. Fuse box 1
8. ABS control unit fuse
9. Fuse box 2
11.ABS motor fuse
12.ABS solenoid fuse
13.Battery positive lead
14.Battery
15.Battery negative lead
16.Engine ground
17.Main switch
18.Fuse
23.Right handlebar switch
26.Front brake light switch
35.ECU(Engine control unit)
43.Rear brake light switch
44.Joint connection 1
45.Joint connection 2
46.Meter assembly
50.ABS warning light
51.Meter light
76.ABS ECU(Electric control unit)
77.Front wheel sensor
78.Rear wheel sensor
79.Joint 4
80.ABS test coupler
