HOW TO USE THIS MANUAL
This manual is intended as a handy, easy-to-read reference book for the mechanic. Comprehensive
explanations of all installation, removal, disassembly, assembly, repair and check procedures are
laid out with the individual steps in sequential order.
● The manual is divided into chapters and each chapter is divided into sections. The current sec-
tion title “1” is shown at the top of each page.
● Sub-section titles “2” appear in smaller print than the section title.
● To help identify parts and clarify procedure steps, there are exploded diagrams “3” at the start of
each removal and disassembly section.
● Numbers “4” are given in the order of the jobs in the exploded diagram. A number indicates a dis-
assembly step.
● Symbols “5” indicate parts to be lubricated or replaced. Refer to “SYMBOLS”.
● A job instruction chart “6” accompanies the exploded diagram, providing the order of jobs, names
of parts, notes in jobs, etc.
● Jobs “7” requiring more information (such as special tools and technical data) are described
sequentially.
