Yamaha MagicStomp - Connections

10
Dyna. Phaser
Phaser effect. The effect changes according to input level.
Tape Echo
Vintage tape echo.
Mono Delay
Basic repeat delay.
Stereo Delay
Basic stereo delay.
Parameter Display Range Description
Decay DCY 6 to 46000 ms Decay speed
FB. Gain FB –99 to +99%
Feedback gain (plus values for normal-phase feedback, minus values for
reverse-phase feedback)
Direction DIR Up, Down Upward or downward frequency change
Sense SENS 0 to 100 Sensitivity
Offset OFST 0 to 100 Lowest phase-shifted frequency offset
Stage STAG 2, 4, 6, 8, 10, 12, 14, 16 Number of phase shift stages
LSH Freq. LSHF 21.2 Hz to 8.00 kHz Low shelving filter frequency
LSH Gain LSHG –12.0 to +12.0 dB Low shelving filter gain
HSH Freq. HSHF 50.0 Hz to 16.0 kHz High shelving filter frequency
HSH Gain HSHG –12.0 to +12.0 dB High shelving filter gain
Mix MIX 0 to 100% Mix level
Parameter Display Range Description
Time DT 0.0 to 10.0 Delay time
Feedback FB 0.0 to 10.0 Delay feedback level
Level LEVL 0.0 to 10.0 Delay level
Parameter Display Range Description
Delay TIME 0.0 to 2730.0 ms Delay time
FB. Gain FB –99 to +99%
Feedback gain (plus values for normal-phase feedback, minus values for
reverse-phase feedback)
High Ratio HRAT 0.1 to 1.0 High-frequency feedback ratio
High Pass Filter HPF Thru, 21.2 Hz to 8.00 kHz High-pass filter cutoff frequency
Low Pass Filter LPF 50.0 Hz to 16.0 kHz, Thru Low-pass filter cutoff frequency
Mix MIX 0 to 100% Mix level
Parameter Display Range Description
Delay L DT.L 0.0 to 1350.0 ms Left channel delay time
Delay R DT.R 0.0 to 1350.0 ms Right channel delay time
FB. Gain L FB.L –99 to +99%
Left channel feedback (plus values for normal-phase feedback, minus
values for reverse-phase feedback)
FB. Gain R FB.R –99 to +99%
Right channel feedback (plus values for normal-phase feedback, minus
values for reverse-phase feedback)
High Ratio HRAT 0.1 to 1.0 High-frequency feedback ratio
High Pass Filter HPF Thru, 21.2 Hz to 8.00 kHz High-pass filter cutoff frequency
Low Pass Filter LPF 50.0 Hz to 16.0 kHz, Thru Low-pass filter cutoff frequency
Mix MIX 0 to 100% Mix level
