11
Mod. Delay
Basic repeat delay with modulation.
Delay LCR
3-tap delay (left, center, right).
Echo
Stereo delay with crossed feedback loop.
Parameter Display Range Description
Wave WAVE Sine, Triangle Modulation waveform
Delay TIME 0.0 to 2725.0 ms Delay time
FB. Gain FB –99 to +99%
Feedback gain (plus values for normal-phase feedback, minus values for
reverse-phase feedback)
Freq. FREQ 0.05 to 40.00 Hz Modulation speed
High Pass Filter HPF Thru, 21.2 Hz to 8.00 kHz High-pass filter cutoff frequency
Low Pass Filter LPF 50.0 Hz to 16.0 kHz, Thru Low-pass filter cutoff frequency
High Ratio HRAT 0.1 to 1.0 High-frequency feedback ratio
Depth DPT 0 to 100% Modulation depth
Mix MIX 0 to 100% Mix level
Parameter Display Range Description
Delay L DT.L 0.0 to 2730.0 ms Left channel delay time
Delay C DT.C 0.0 to 2730.0 ms Center channel delay time
Delay R DT.R 0.0 to 2730.0 ms Right channel delay time
Delay FB. DTFB 0.0 to 2730.0 ms Feedback delay time
Level L LV.L –100 to +100% Left channel delay level
Level C LV.C –100 to +100% Center channel delay level
Level R LV.R –100 to +100% Right channel delay level
FB. Gain FB –99 to +99%
Feedback gain (plus values for normal-phase feedback, minus values for
reverse-phase feedback)
High Ratio HRAT 0.1 to 1.0 High-frequency feedback ratio
High Pass Filter HPF Thru, 21.2 Hz to 8.00 kHz High-pass filter cutoff frequency
Low Pass Filter LPF 50.0 Hz to 16.0 kHz, Thru Low-pass filter cutoff frequency
Mix MIX 0 to 100% Mix level
Parameter Display Range Description
Delay L DT.L 0.0 to 1350.0 ms Left channel delay time
Delay R DT.R 0.0 to 1350.0 ms Right channel delay time
FB. Delay L DTFL 0.0 to 1350.0 ms Left channel feedback delay time
FB. Delay R DTFR 0.0 to 1350.0 ms Right channel feedback delay time
FB. Gain L FB.L –99 to +99%
Left channel feedback gain (plus values for normal-phase feedback,
minus values for reverse-phase feedback)
FB. Gain R FB.R –99 to +99%
Right channel feedback gain (plus values for normal-phase feedback,
minus values for reverse-phase feedback)
L->R FB. Gain L->R –99 to +99%
Left to right channel feedback gain (plus values for normal-phase feed-
back, minus values for reverse-phase feedback)
R->L FB. Gain R->L –99 to +99%
Right to left channel feedback gain (plus values for normal-phase feed-
back, minus values for reverse-phase feedback)
High Ratio HRAT 0.1 to 1.0 High-frequency feedback ratio
High Pass Filter HPF Thru, 21.2 Hz to 8.00 kHz High-pass filter cutoff frequency
Low Pass Filter LPF 50.0 Hz to 16.0 kHz, Thru Low-pass filter cutoff frequency
Mix MIX 0 to 100% Mix level
