Short + Medium + Long Mod. Delay
3 band multi tap delay w/3 delay times.
*n = delay band no.
Reverb
Hall, room, stage, and plate reverb simulations, all with gates.
Parameter Display Range Description
Wave Form W.F. Triangle, Saw Up, Saw Down
Selects the modulation waveform used for “other” in the Wave Parame-
ter below.
Effect Level ELVL 0.0 to 10.0 Effect level
Direct Level DLVL 0.0 to 10.0 Level of direct sound
Direct Pan DPAN L10.0 to R10.0 Pan for direct sound
* Edit window no. corresponds to delay band no. and tap no.
Page1:Band1 Tap1, Page2:Band2 Tap1, Page3:Band2 Tap2, Page4:Band2 Tap3,
Page5:Band3 Tap1, Page6:Band3 Tap2, Page7:Band3 Tap3, Page8:Band3 Tap4
Time DTn
Band1:0.1 to 696.0 ms,
Band2:0.2 to 2180.0 ms,
Band3:0.2 to 2920.0 ms
Delay time (Page1, Page2, Page5 only)
Low Cut Filter LCFn Off to 10.0 Filter cuts low frequencies (Page1, Page2, Page5 only)
High Cut Filter HCFn Off to 10.0 Filter cuts high frequencies (Page1, Page2, Page5 only)
Feedback FBn 0.0 to 10.0 Delay’s feedback level (Page1, Page2, Page5 only)
Wave WAVn Sine, Other
Modulation waveform. Sine wave or other (“other” is the wave selected
in the Wave Form Parameter above).
Phase PHSn Normal, Reverse Phase of the delay
Tap TAPn 0 to 100 %
The output time of the delay sound in regard to the time of the delay
loop (see page 31)
Speed SPDn 0.0 to 10.0
Modulation speed (modulation phase if the band is synchronized with
another band)
Depth DPTn 0.0 to 10.0 Modulation depth
Pan PANn L10.0 to R10.0 Position in the stereo field of the delay sound.
Level LVLn 0.0 to 10.0 Delay level
Sync SYNn 1 to 8
Setting to synchronize the modulation of different bands (set to any
number other than the band number of the current band, it will syn-
chronize with that band. If set to the same number as the current band,
it will not synchronize.)
Parameter Display Range Description
Reverb Type TYPE Hall, Room, Stage, Plate Reverb type
Initial Delay IDLY 0.0 to 500.0 ms Initial delay before reverb begins
ER/Rev Delay ERDL 0.0 to 100.0 ms Delay between early reflections and reverb
Reverb Time TIME 0.3 to 99.0 s Reverb time
High Ratio HRAT 0.1 to 1.0 High-frequency reverb time ratio
Low Ratio LRAT 0.1 to 2.4 Low-frequency reverb time ratio
Diffusion DIFF 0 to 10 Reverb diffusion (left–right reverb spread)
Density DNST 0 to 100% Reverb density
ER/Rev Balance ERBL 0 to 100%
Balance of early reflections and reverb
(0% = all reverb, 100% = all early reflections)
High Pass Filter HPF Thru, 21.2 Hz to 8.00 kHz High-pass filter cutoff frequency
Low Pass Filter LPF 50.0 Hz to 16.0 kHz, Thru Low-pass filter cutoff frequency
Gate Level GATE Off, –60 to 0 dB Level at which gate kicks in
Attack ATCK 0 to 120 ms Gate opening speed
Hold HOLD 0.02 to 2040 ms Gate open time
Decay DCAY 6 to 44500 ms Gate closing speed
Mix MIX 0 to 100% Mix level
