67
MOX6/MOX8
34 034 ROM 2 (Full) Checks the ROM. (Full check)
Check the ROM that is connected to the CPU. (Read/Write operation. Full Address Check SUM
comparison.)
After executing the test, confi rm that "OK" is displayed on the LCD.
(OK:"OK", NG:"NG")
Note: If the test no.6 (All memory simple check) is executed, this test can be skipped.
35 035 RAM 2 (Full) Checks the RAMs. (Full check)
Check the RAMs that are connected to the CPU. (Read/Write operation for all area.)
After executing the test, confi rm that "OK" is displayed on the LCD.
(OK:"OK", NG:"NG")
Note: If the test no.6 (All memory simple check) is executed, this test can be skipped.
36 036 WaveROM 2(Full) Checks the wave ROMs. (Full check)
Check the wave ROMs that are connected to the tone generator. (Read operation. Full Address
Check SUM comparison.) It takes about 95 seconds.
After executing the test, confi rm that "OK" is displayed on the LCD.
(OK:"OK", NG:"NG")
Note: If the test no.6 (All memory simple check) is executed, this test can be skipped.
37 037 FX RAM 2(Full) Checks the effect RAMs. (Full check)
Check the effect RAMs that are connected to the tone generator. (Read/Write operation for all area.)
It takes about 40 seconds.
After executing the test, confi rm that "OK" is displayed on the LCD.
(OK:"OK", NG:"NG")
Note: If the test no.6 (All memory simple check) is executed, this test can be skipped.
38 038 PANEL A (Sw) Checks the panel switches and LEDs on the PNA circuit board.
It is the same as the test no.13. (Refer to the test no.13 for more details.)
39 039 PANEL B (Sw) Checks the panel switches and LEDs on the PNB circuit board.
It is the same as the test no.13. (Refer to the test no.13 for more details.)
40 040 PANEL C (Sw) Checks the panel switches and LEDs on the PNC circuit board.
It is the same as the test no.13. (Refer to the test no.13 for more details.)
41 041 PANEL A (Enc) Checks the encoders on the PNA circuit board.
It is the same as the test no.21. (Refer to the test no.21 for more details.)
42 042 PANEL B (Enc) Checks the encoder on the PNB circuit board.
It is the same as the test no.21. (Refer to the test no.21 for more details.)
43 043 Power Off Checks the auto power off function.
Execute the test. The power is down automatically.
Confi rm the LCD displays nothing and the LCD backlight is turned off at that time.
Press the [STANDBY/ON] switch again to release the latch of the switch.
44 044 Output Full R Full Level Output R Check
Outputs the signal with full level (0 dBFS) from the OUTPUT [R] terminal.
(As for the test no.9 (OUTPUT R Check), the output signal level is -12dBFS.)
45 045 Output Full L Full Level Output L Check
Outputs the signal with full level (0 dBFS) from the OUTPUT [L/MONO] terminal.
(As for the test no.10 (OUTPUT L Check), the output signal level is -12dBFS.)
46 046 Factory Set Factory Set
All data is reset to the factory default.
After executing the factory set, "OK" is displayed on the LCD.
(OK:"OK")
47 047 Test Exit Test Exit
Exits from the test mode, and reboots to the normal mode.
Caution: Keep the power on during the reboot.
TEST
LCD display
Test description, judging conditions, etc.
No.
To Next Page
