124 PSR-A5000 Reference Manual
Page 1/2
Page 2/2
This function is used to “lock” specific parameters (effect, split point, etc.) to make them selectable only via the panel
control—in other words, instead of being changed via Registration Memory, One Touch Setting, Playlist, or Song and
sequence data.
To lock the desired parameter group, touch the corresponding box to enter the checkmark. To unlock the parameter,
touch the box again.
This lets you execute the Format operation or check the memory capacity (approximate value) of the internal User
drive or the USB flash drive connected to the [USB TO DEVICE] terminal.
To format the internal User drive or the connected USB flash drive, touch the name of the desired drive to be formatted
in the device list, and then touch [Format].
Touch Screen/Display
Touch Screen Sound Determines whether or not touching the display will trigger the click sound.
When this is set to “Speaker only,” the sound is triggered by touching and is output to the
speaker, but not to the MAIN OUTPUT jacks and the PHONES jack.
Calibration For calibrating the display when it does not respond properly to your touch. (Normally, this
need not be set, since it is calibrated by factory default.) Touch here to call up the Calibration
display, and then touch the center of the plus marks (+) in order.
Brightness Screen Adjusts the brightness of the display.
Button Lamps Adjusts the brightness of the button lamps.
Display Pop-up Display
Time
Determines the time that elapses before the pop-up windows close. Pop-up windows appear
when you press buttons such as TEMPO, TRANSPOSE or UPPER OCTAVE, etc. When
“Hold” is selected here, the pop-up window is shown until you close it.
Transition
Effect
Turns on or off the Transition Effect which is applied when the display is changed.
File Selection Time Stamp Determines whether the time stamp of a file is shown on the User tab of the File Selection
display or not.
Dial Operation Determines whether or not a file is loaded instantly when it is selected with the Dial. The fol-
lowing are the options.
• Select: A file is loaded with selecting operation.
• Move Cursor Only: A file is not actually loaded until [Enter] is pressed. A cursor appears
to indicate the current selection.
Parameter Lock
For details on which parameters belong to each group, refer to the Data List (Parameter Chart) on the website.
Storage—Formatting the Drive
The Format operation deletes any previously existing data. Make sure that the User drive or the USB flash drive you are formatting does not con-
tain important data. Proceed with caution, especially when connecting multiple USB flash drives.
The time can be set on the display called up via [MENU] [Time]. For details, refer to page 122.
