APPENDIX
Specifications
En 165
•Maximum Input Level
PHONO (1 kHz, 0.1% THD) ................................... 60 mV or more
AUDIO2 etc. (1 kHz, 0.5% THD) .............................. 2.4 V or more
• Output Level/Output Impedance
AV OUT....................................................................200 mV/1.2 kΩ
HEADPHONE OUT .................................................150 mV/100 Ω
PRE OUT......................................................................1.0 V/1.2 kΩ
ZONE2 OUT ................................................................1.0 V/1.2 kΩ
ZONE3 OUT ................................................................1.0 V/1.2 kΩ
• Frequency Response
AUDIO2 etc. to FRONT L/R
(Pure Direct, 10 Hz to 100 kHz)..........................................+0/-3 dB
• Total Harmonic Distortion
PHONO to AV OUT (20 Hz to 20 kHz, 1 V).............. 0.02% or less
AV1 to FRONT L/R (20 Hz to 20 kHz, 65 W/8 Ω)..... 0.04% or less
• Signal to Noise Ratio (IHF-A Network)
PHONO (input shorted, 5 mV) to AV OUT
[U.S.A. and Canada models] ......................................86 dB or more
[Australia model]........................................................81 dB or more
AUDIO2 etc. (input shorted, 250 mV) to FRONT L/R
..................................................................................100 dB or more
• Residual Noise (IHF-A Network)
FRONT L/R................................................................150 µV or less
• Channel Separation (1 kHz/10 kHz)
PHONO (input shorted)...................................60 dB/55 dB or more
AV1 etc. (input 5.1 kΩ shorted)....................... 60 dB/45 dB or more
• Volume Control
Main Zone ................................................... MUTE/-80 to +16.5 dB
Zone2, Zone3............................................... MUTE/-80 to +16.5 dB
• Tone Control Characteristics
Main Zone (FRONT, CENTER, SUBWOOFER)
Bass Boost/Cut........................................................... ±6 dB/50 Hz
Bass Turnover Frequency.................................................... 350 Hz
Treble Boost/Cut ...................................................... ±6 dB/20 kHz
Treble Turnover Frequency................................................ 3.5 kHz
Zone2, Zone3
Bass Boost/Cut....................................................... ±10 dB/100 Hz
Bass Turnover Frequency.................................................... 350 Hz
Treble Boost/Cut.....................................................±10 dB/10 kHz
Treble Turnover Frequency ................................................3.5 kHz
• Filter Characteristics (fc=40/60/80/90/100/110/120/160/200 Hz)
H.P.F. (FRONT, CENTER, SURROUND, SURROUND BACK:
Small) ................................................................................12 dB/oct.
L.P.F. (SUBWOOFER) .....................................................24 dB/oct.
■ Video Section
• Video Format (MONITOR OUT/ZONE OUT, Wall Paper/OSD)
[U.S.A. and Canada models] ........................................NTSC/PAL
[Australia model]..........................................................PAL/NTSC
• Video Signal Type (Video Conversion) .............................NTSC/PAL
• Signal Level
Composite ..................................................................... 1 Vp-p/75 Ω
S-Video
- NTSC ................................1 Vp-p/75 Ω (Y), 0.286 Vp-p/75 Ω (C)
- PAL .......................................1 Vp-p/75 Ω (Y), 0.3 Vp-p/75 Ω (C)
Component ...................... 1 Vp-p/75 Ω (Y), 0.7 Vp-p/75 Ω (P
B/PR)
• Maximum Input Level (Video Conversion Off) .......1.5 Vp-p or more
• Signal to Noise Ratio (Video Conversion Off) ............. 60 dB or more
• Frequency Response (Video Conversion Off)
Component
(MONITOR OUT/ZONE OUT) ............... 5 Hz to 100 MHz, ±3 dB
■ FM Section
• Tuning Range
[U.S.A. and Canada models] ............................ 87.5 to 107.9 MHz
[Australia model].......................................... 87.50 to 108.00 MHz
• 50 dB Quieting Sensitivity (IHF)
Mono ...................................................................... 3.0 µV (20.8 dB)
• Signal to Noise Ration (IHF)
Mono/Stereo..................................................................74 dB/70 dB
[U.S.A. model] HD ..................................................................80 dB
• Harmonic Distortion (1 kHz)
Mono/Stereo.....................................................................0.3%/0.3%
[U.S.A. model] HD ................................................................. 0.03%
• Antenna Input ........................................................ 75 Ω (unbalanced)
■ AM Section
• Tuning Range
[U.S.A. and Canada models]................................530 to 1710 kHz
[Australia model] .................................................531 to 1611 kHz
■ General
• Power Supply
[U.S.A. and Canada models]............................... AC 120 V, 60 Hz
[Australia model] ................................................ AC 240 V, 50 Hz
• Power Consumption
[U.S.A. model] ........................................................490 W/620 VA
[Canada model] .......................................................400 W/510 VA
[Australia model] .................................................................490 W
• Standby Power Consumption
HDMI Control Off/Standby Through Off.....................0.3 W or less
HDMI Control On/Standby Through On.................. 2.7 W (typical)
NET Standby On....................................................... 4.5 W (typical)
• Dimensions (W x H x D)
............................... 435 x 182 x 430 mm (17-1/8 x 7-1/8 x 16-7/8 in)
• Weight..................................................................... 16.0 kg (35.3 lbs.)
