Yamatake Corporation Operation Using SFC
ST3000 Smart Transmitter Series 900 Electronic Differential Pressure/Pressure Transmitter 6-7
6-2-4-2 Key names and function (for Orange keys)
This section describes the functions assigned to the orange keys, which are mainly
used to communicate with the transmitter or to select a screen or to select from the
menu.
Button
Description
When pressed alone at cursor
When pressed after SHIFT
key
No effect No effect
NEXT: Scrolls up the screen in the
CONFIG function.
No effect
PREV: Scrolls down the screen in
the CONFIG function.
No effect
OUTPUT: Displays a value in per-
centage, which is transmitted by
the transmitter to the control loop.
INPUT: Displays the differen-
tial pressure being input to the
transmitter.
CORRECT: Press this key to
adjust the zero point of the trans-
mitter. This operation is available
while INPUT (input) is being read.
No effect
ENTER: Press this key to answer
“Yes” to a question on the screen.
The screen will move one step up
or down or data set by the SFC is
written into the database of the
transmitter.
NON-VOL: The data set by
the SFC is forcibly written into
non-volatile memory of the
transmitter.
G
SET
H
NEXT
L
PREV
OUT-
J
PUT
INPUT
COR-
K
RECT
RESET
ENTER
( Yes )
NON-VOL
