Operation Using SFC Yamatake Corporation
6-28 ST3000 Smart Transmitter Series 900 Electronic Differential Pressure/Pressure Transmitter
6-7-4 :Display or Change Indicator Display Format (Flow Rate /Linear/
Display Flow Rate)
This function enables displaying or changing the display format, of the indicator.
• When the output format is Square Root, the display format is fixed to Flow
Rate (FLOW).
• When the output format is LINEAR, select either LINEAR or DISP FLOW for
the display format.
~Note Display Flow Rate: In some cases, for processing by higher level equip-
ment, the required output format of a transmitter is Linear. Select Flow
Rate can be selected for the indicator display format when the transmitter
output format is Linear.
~Note For detailed information on the indicator, refer to 5.8.
Display or change the display format (linear/display flow rate) of the transmitter indi-
cator using this procedure:
Step Description SFC screen
1
Press the key.
2
Press the key.
3
Press the key.
Displays the currently-selected display for-
mat (flow rate, linear or display flow rate).
(Output format: Square)
or (Display format: Linear)
(Display format: Display
Flow Rate)
B
CONF
DSTJ CONFIG
CONFORM?
H
NEXT
DSTJ CONFIG
DISPLAY?
ENTER
( Yes )
NON-VOL
DISPLAY CONF
FLOW
DISPLAY CONF
LINEAR
DISPLAY CONF
ENTERED IN SFC
