Operation Using SFC Yamatake Corporation
6-20 ST3000 Smart Transmitter Series 900 Electronic Differential Pressure/Pressure Transmitter
6-5-2-1 Printing example
An example of printed data is shown, below. The meanings of individual lines are
explained.
Printing example Meaning
Tag No. FIT 1234
‘01-01-01 10:00
TYPE : DIFF, PRESSURE
ANA/DE : ANALOG XMTR
FORM : LINEAR
(or SQUARE ROOT)
PROM# : 2104695800
SW VER : B.1
DAMP : 0.00 s
SPAN : 70.00 kPa
LRV : 10.00 kPa
URV : 99.64 kPa
URL : 99.64 kPa
F/SAFE : DOWNSCALE
HEIGHT : 0.0000 m\
DISPLAY
CONF : DISP FLOW
TYPE : EBG. UNIT
EULO : -10.000
EUHI : 50.00
INPUT : 45.00 kPa
OUTPUT : 50.0%
SV : T = 25
°C (77°F)
STATUS CHECK= OK
Tag No.
Date. time
Type
Output mode
Output format
PROM No.
Software version
Damping time constant
Span
Measured value corresponding to 0% output
Measured value corresponding to 100% output
Maximum value of set range
Burnout direction
Tank flange height
Display format
Display type
Low limit of engineering quantity
High limit of engineering quantity
Input differential pressure to transmitter
Transmitter output (%)
Self-diagnosis result of transmitter
To Next Page
