1-3: Symbols on Communicator Screen
1-4: Keying in Alphanumeric Characters
To key in an alphabet at the top of a key, press the arrow key indicating the position of
the character on the key, then press the alphanumeric key.
+ = A
Flashing heart icon in the upper right corner indicates that the transmit-
ter and communicator are communicating.
This left arrow symbol indicates that the left arrow on the keypad
brings you back to previous menu.
or These arrows indicate there is more column to scroll though, using the
indicated arrow on the keypad.
This right arrow indicates a menu item has menu option.
