Operation of the Transmitter Yamatake Corporation
5-18 ST3000 Smart Transmitter Series 900 Electronic Differential Pressure/Pressure Transmitter
5-3-2-2 Starting Measurement
Procedure
Operate the valves using this procedure, to apply process pressure to the transmitter
and display the measured value by operating the SFC.
• How to apply process pressure
Step Description
1 Open the local valve gradually.
Vent / Drain plug
High-pressure side
Local valve
To Next Page
