ST3000 Smart Transmitter Series 900 Electronic Differential Pressure/Pressure Transmitter 6-23
6-7 : Display and Change Transmitter Setting
6-7-1 :Overview
Applicable setting
The following settings (values and states) can be displayed or changed by operating
SFC keys. This operation can be executed even during measurements.
The following settings (values and states) can be displayed or changed by operating
SFC keys. This operation can be executed even during measurements.
a: Enabled -: Disabled
Save settings
After changing settings (values and states), save settings using this procedure.
Remarks:
Settings (values and states) that are input to the transmitter are automatically saved
after about 30 seconds. They are not erased by switching OFF the transmitter.
Item Change Display
Tag No.
aa
Output format
aa
Display format
aa
High and low limits of engineering quantity
aa
Low limit of set range
aa
High limit of set range
aa
Span of set range
aa
Engineering unit
aa
Damping-Time constant
aa
Low flow cutoff value
aa
Burnout direction
- a
PROM No.
- a
Software version
- a
Sensor temperature
- a
Step Description SFC screen
1
Press the and keys, in that order.
• The data has been saved in the transmit-
ter.

SHIFT
ENTER
( Yes )
NON-VOL
SHIFT-
DSTJ FIT-1234
WORKING...
DSTJ FIT-1234
DATA NONVOLATILE
