PRODUCT OVERVIEW
30 JH Series Operation Manual
When the warning devices are activated and normal operation is impossible, stop the
engine and do not use it until the problem has been solved.
Accessory power output
The harness attached to the panel has a terminal where the signal that is synchronized to
the panel power supply can be taken off. (Figure 17) (Refer to the Wiring Diagrams on
page 137.)
The maximum current of this output terminal is 3 A. Do not use a current higher than 3 A.
For the content of the output terminal, refer to the Wiring Diagrams on page 137.
Figure 3
Figure 17
043801-00E00
F1A - 3 AMP Fuse
Buzzer
ACC Output
