6 Maintenance by the operator
160
1. Loosen the two screws and rotate the bottom cover
to access the lubrication nipple.
a = Cover
2. Raise the machine with the equipment by activat-
ing the command lever.
3. Loosen the greaser.
4. Let the grease escape so that the track will extend.
1 = Greaser
b = Track roller
c = Track
5. Tighten the greaser.
Tightening torque : 49,0 N•m.
6. Proceed with the track tensioning.
7. Check the tension again. If it is still not correct, ad-
just it again.
8. Wipe off the excess grease with a cloth or
equivalent.
9. Re-install the cover.
IMPORTANT
The rubber track does not resist grease. Wipe the grease off completely as it may reduce
the life time of the rubber tracks.
6.5.5 Releasing the tension
WARNING
Do not loosen the greaser by more than one turn.
If it is loosened suddenly, the high pressure grease in-
side may escape or the valve may be ejected, which
may cause serious injury.
When you check whether the grease has escaped, do not look inside the greaser but check
that the track is released. Do not place your face, hand, legs or body in the direction of
the greaser.
It is very dangerous to remove the grease using procedures other than those described
here. If the track cannot be relaxed, ask your YANMAR dealer to intervene.
