46
9 OPTIONS
• Mounting options that are not authorised by YANMAR may cause accidents and reduce the
machine's life span.
• The installation and use of unauthorised parts may lead to the warranty being cancelled.
9.1 Long arm
• The machine can be fitted when this option is requested.
• Use of hydraulic hammer is not recommended with the long arm.
9.2 Additional counterweights
• The machine can be equipped
with an additional counterweight
that gives it better stability and
greater lifting capacities.
1= Additional counterweights
9.3 Lifting Kit
WARNING
Do not perform lifting operations without the lifting equipment listed below being instal-
led on the machine.
13 Load lifting, page 115
9.3.1 Lifting ring
• An appropriate ring is required to suspend a load with the machine. For more details,
contact your dealer.
• The lifting ring welded to the tie rod must be installed with safety valves.
• Check whether the ring and the ring mounting base are damaged. If you detect any da-
mage, ask your dealer to intervene.
• This option is subject to periodic inspection.
IMPORTANT
There is a risk that the metal cable or the suspension hook may be detached from the ring
if the ring is not in a vertical position.
Install a device that can oppose the accidental release of the load on the machine's lifting
ring (with latch hook, shackle, eye...) and whose WLL
1
is equal to or greater than the load
to be lifted.
