Yanmar ViO80-1A - 4 Th Hydraulic Circuit Control (P.T.O. 2)

5 Description of the driving position
28
5.3.5 4th hydraulic circuit control (P.T.O. 2)
1= Proportional roller
2= Knob
P.T.O. switch
• Use the proportional roller to adapt the dual effect P.T.O. rate.
• Dual action accessory (tilt bucket, auger, etc.) : operate only the proportional roller.
1= Proportional roller
Adjustable proportional PTOAdjustable proportional PTO
• The adjustable proportionality allows better P.T.O flow control by combining a knob with
the proportional roller.
1= Proportional roller
2= Knob
• To use the adjustable proportionality system:
1. Operate the accessory with the proportional roller.(1)
2. Set the maximum hydraulic circuit speed with the knob. (2)
• Turn the button clockwise to increase the flow
rate.
• Turn the button counter-clockwise to decrease the
flow rate.
