Yardline OAKRIDGE 8 x 12 User Manual

16
3/4"
(1,9 cm)
48"
(121,9 cm)
12"
(30,5 cm)
6"
(15,2 cm)
Flush
44-5/8"
(113,3 cm)
12"
(30,5 cm)
6"
(15,2 cm)
Flush
Forsquarenessmaintainushand
3/4"measurementalongpaneledges.
Forsquarenessmaintainush
alongpaneledges.
Place center 48"x72" panel on frame
as shown with primed side facing up.
Nail using 2" nails 6" apart on edges
and 12" apart inside panel.
6
Place end 44-5/8"x72"panel on frame
as shown with primed side facing up.
Nail using 2" nails 6" apart on edges
and 12" apart inside panel.
7
You have nished building your LEFT WALL.
FINISH
9
Primed
sideup
Primed
sideup
48 x 72"
(121,9 x 213,4 cm)
44-5/8 x 72"
(121,9 x 213,4 cm)
x1 x1
x90
LEFT SIDE WALL PANELS
PARTSREQUIRED:
2" (5,1 cm)
8
Carefully ip the LEFT wall over.
DOORDOOR
3/4"GAUGE
BLOCK
3/4"GAUGE
BLOCK
