UN
x1
2 x 4 x 94-1/2" (5,1 x 10,2 x 240 cm)
23
3" (7,6 cm)
x8
BACK WALL
PARTSREQUIRED:
Flush
Center UN on back wall top plate and ush to inside of back of wall panel (Fig.A).
While keeping UN ush, secure to top plate using eight 3" screws.
2
1
BEGIN
3"(7,6cm)
Screws
3"(7,6cm)
Screws
CENTERONTOPPLATE
INSIDEOFSHED
UN
UN
Fig.A
