Installation 1-3
Unpack and Inspect
Prior to unpacking, check the package label and verify that the product received matches the product ordered. Unpack the option and verify
that the following items are included in the product package and are undamaged.
Fig 1.1 – V7 Ethernet/IP Option Kit CM093
Table 1.1 – V7 EtherNet/IP Option CM093 Parts
CM093 Kit Parts Qty.
V7 EtherNet/IP Option CM093 Ring Kit 1
Option Mounting Bracket 1
Mounting Bracket Screw 1
Ferrite (Power & Motor Leads) 2
Ferrite (Ethernet Cable) 1
Cable Ties 3
Installation Guide (IG.V7.26) 1
