YASKAWA CIMR-V7AM

EtherNet/IP 3-2
Supported Output Instances
 Basic Speed Control Output Instance 20 (14h)
Run Forward: Forward RUN Command
Fault Reset: Fault Reset Command
Speed reference: RPM when n035 = (2 ~ 39)
 Extended Speed Control Output Instance 21 (15h)
Run Forward: Forward RUN Command
Run Reverse: Reverse RUN Command
Fault Reset: Fault Reset Command
Net Control: Parameter n003
0 - 1 transition sets n003 = 3
1 - 0 transition sets n003 to previous value
Net Reference: Parameter n004
0 - 1 transition sets n004 = 9
1 - 0 transition sets n004 to previous value
Speed Reference: RPM when n035 = (2 ~ 39)
Output Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Instance 0 - - - - -
Fault
Reset
-
Run
Forward
20 (14h)
1 -
2 Speed Reference (Low Byte) [n035 Scaled]
3 Speed Reference (High Byte) [n035 Scaled]
Output Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Instance 0 -
Net
Reference
Net
Control
- -
Fault
Reset
Run
Reverse
Run
Forward
21 (15h)
1 -
2 Speed Reference (Low Byte) [n035 Scaled]
3 Speed Reference (High Byte) [n035 Scaled]
