YASKAWA CIMR-V7AM

EtherNet/IP 3-6
Supported Input Instances
 Basic Speed Control Input Instance 70 (46h)
Faulted: Drive Fault
Running1 (Forward): Running in forward direction
Speed Actual: RPM if n035 = (2 ~ 39)
 Extended Speed Control Input Instance 71 (47h)
Faulted: Drive Fault
Warning: Drive Alarm
Running1 (FWD): Running in forward direction
Running1 (REV): Running in reverse direction
Ready: Drive Ready
Control from Net: 0 = Non-network control
1 = Control from network
Reference from Net: 0 = Reference not from network
1 = Reference from network
At Speed: Speed Agree
peed Actual: RPM if n035 = (2 ~ 39)
Input Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Instance 0 - - - - -
Running 1
(FWD)
- Faulted
70 (46h)
1 -
2 Speed Actual (Low Byte) [n035 Scaled]
3 Speed Actual (High Byte) [n035 Scaled]
Input Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Instance 0 At Speed
Reference
from Net
Control
from Net
Ready
Running 2
(REV)
Running 1
(FWD)
Warning Faulted
71 (47h)
1 -
2 Speed Actual (Low Byte) [n035 Scaled]
3 Speed Actual (High Byte) [n035 Scaled]
