10 Attachment
286 YASKAWA TOMPC71061753A YASKAWA AC Drive GA500 Installation and Operation Instruction
Mode
l
Terminal
Recommen
ded Gauge
mm
2
Applicable
Gauge
mm
2
Wire
Stripping
Length
*1
mm
Terminal Screw
Tightening
Torque
N∙m (in∙lb)
Size Shape
2042
R/L1, S/L2, T/L3 10 2.5 - 16 10 M4
1.5 - 1.7
(13.5 - 15)
U/T1, V/T2, W/T3 10 2.5 - 16 10 M4
1.5 - 1.7
(13.5 - 15)
-, +1, +2 16 4 - 25 18 M5
2.3 - 2.5
(19.8 - 22)
B1, B2 4 2.5 - 6 10 M4
1.5 - 1.7
(13.5 - 15)
10 6 - 16 - M5
2.0 - 2.5
(17.7 - 22.1)
2056
R/L1, S/L2, T/L3 16 4 - 25 18 M5
2.3 - 2.5
(19.8 - 22)
U/T1, V/T2, W/T3 16 4 - 25 18 M5
2.3 - 2.5
(19.8 - 22)
-, +1, +2 25 6 - 35 18 M5
• ≤ 25 mm
2
2.3 - 2.5
(19.8 - 22)
• 35 mm
2
≤
4.1 - 4.5
(36 - 40)
B1, B2 10 4 - 16 10 M4
1.5 - 1.7
(13.5 - 15)
10 10 - 25 - M6
5.4 - 6.0
(47.8 - 53.1)
2070
R/L1, S/L2, T/L3 25 6 - 35 20 M6
5 - 5.5
(45 - 49)
U/T1, V/T2, W/T3 16 6 - 25 20 M6
5 - 5.5
(45 - 49)
-, +1, +2 35 10 - 50 20 M6
5 - 5.5
(45 - 49)
B1, B2 10 4 - 16 10 M4
1.5 - 1.7
(13.5 - 15)
16 10 - 25 - M6
5.4 - 6.0
(47.8 - 53.1)
