YASKAWA G7 User Manual

15
Run/Stop and Frequency Reference
The Run/Stop and Frequency Reference commands can originate from:
 Serial communication (Built-in Modbus: Keypad or R+/-, S+/- Terminals)
 Keypad (Digital Operator)
 Terminal Strip
 Option Card
Parameter B1-01 (Run/Stop Method Selection) allows the selection of the origin of the Run/Stop command. Parameter B1-02 (Reference
Selection) allows the selection of the origin of the Frequency Reference command. The Run/Stop and Frequency Reference commands may
have different origins.
For example, the Run/Stop command may be set to Terminals (B1-01=1) while the Frequency Reference command may be set to Serial
Communication (B1-02=2).
 Run/Stop Source
Table 1.7 Run/Stop Method Selection
B1-01 Operation Method Selection (Run/Stop)
0 Keypad
1 Terminal Strip (Default Setting)
2 Serial Communication (Built-in Modbus: Keypad or R+/-, S+/- Terminals)
3 Option Card (EtherNet/IP, Modbus TCP/IP, DeviceNet, Profibus DP, LonWorks, etc.)
4 Pulse Input (RP Terminal)
 Frequency Reference Source
Table 1.8 Frequency Reference Source Selection
B1-02 Frequency Reference Selection
0 Keypad
1 Terminal Strip (Default Setting)
2 Serial Communication (Built-in Modbus: Keypad or R+/-, S+/- Terminals)
3 Option Card (EtherNet/IP, Modbus TCP/IP, DeviceNet, Profibus DP, LonWorks, etc.)

YASKAWA G7 Specifications

General

Type	DC Drive
Enclosure Rating	IP20
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Communication Interface	RS-485
Humidity	5 to 95% (non-condensing)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
