Monitor Registers (Read Only)
The following table lists monitor parameters for the G7 drive. These parameters are used to monitor G7 drive information and cannot be written.
 The “U-##” column contains the reference, if it exists, to the “U” monitor, parameter displayed via the operator keypad.
 The “Address” column contains the register addresses for that parameter in hexadecimal format. G7 drive registers are always referred
to in hexadecimal format.
 The “Function” column contains the register name.
 The “Bit” column contains the list of available bits for that register. If the “Bit” column is empty, the register contains word data and
the individual bits are meaningless.
 The “Description” column contains a short description of each register or register bit.
 Reserved registers and data are meaningless and should be ignored.
Table 4.3 G7 Monitor Registers (Read only)
U-## Addr. Function Bit Description
0h Run
1h Reserved
2h Reserved
3h Fault Reset Signal
4h Speed Agree
5h Inverter Ready
6h Minor Fault (Alarm)
7h Major Fault
8h Reserved
9h Reserved
Ah Reserved
Bh Reserved
Ch Reserved
Dh Reserved
Eh Frequency Reference Source (0 = b1-01 Setting, 1 = Modbus Communication)
0010h Inverter Status
Fh Run Command Source (0 = b1-02 Setting, 1 = Modbus Communication)
0h OPE - Keypad Setting Error
1h ERR - EEPROM Write Failure
2h PRG - Keypad Programming Mode
3h 0: Digital Operator Present, 1: PC Connected
0011h Operator Status
4h-Fh Reserved
0h Reserved
1h OPE01 - drive kVA Setting Error (O2-04)
2h OPE02 - Parameter Setting Out of Range
3h OPE03 - Multi-Function Digital Input Setting Error
4h Reserved
5h OPE05 - Run Command Selection Error - Option Card Missing
6h OPE06 - Control Method Selection Error - PG Option Card Missing
7h OPE07 - Multi-Function Analog Input Selection Error
8h OPE08 - Function Selection Error for Current Control Mode
9h OPE09 - PID Control Setup Error
Ah OPE10 - V/F Parameter/Pattern Setting Error
Bh OPE11 - Carrier Frequency Setting Error
Ch Reserved
Dh Reserved
Eh Reserved
0012h OPE – Keypad Setting Error
Fh
Reserved
