YASKAWA G7 User Manual

40
RS-422/RS-485 Self-Test
The G7 drive can perform a self-test of the communications interface. To perform the self-test:
 Apply power to the G7 drive.
 Set parameter H1-05 to 67 (communication self-test). Terminal S7 is just an example. Any terminal can be used.
 Remove power from the G7 drive and wait for the charge lamp to be completely extinguished. Wait at least five additional minutes for
the G7 drive to be completely discharged. Measure the DC bus voltage and verify that it is at a safe level.
 Connect jumper wires to the following G7 drive control terminals (see picture below):
- Connect S+ to R+
- Connect S- to R-
- Connect S7 to SC
 Reapply power to the G7 drive.
Successful Self-Test
- The frequency reference is displayed on the digital operator if the communications interface is functioning normally.
Unsuccessful Self-Test
- If “CE” is displayed on the keypad, the communications interface is not functioning properly. Contact the factory for assistance.
Figure 3.1 RS-422/RS-485 Self-Test Example using Terminal S7

YASKAWA G7 Specifications

General

Type	DC Drive
Enclosure Rating	IP20
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Communication Interface	RS-485
Humidity	5 to 95% (non-condensing)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
