YASKAWA G7 User Manual

26
 Loop-Back Normal Response
The normal Loop-Back Test response is identical to the command message.
Table 2.9 Loop-Back Normal Response Message
Description Data
Slave Address 01h
Function Code 08h
Upper 00h
Test Code
Lower 00h
Upper A5h
Data
Lower 37h
Upper DAh
CRC-16
Lower 8Dh
 Loop-Back Fault Response
Table 2.10 Loop-Back Fault Response Message
Description Data
Slave Address 01h
Function Code 88h
Error Code 01h
Upper 87h
CRC-16
Lower C0h
The fault response message contains the same slave address as the command message, indicating to the master which slave is responding. The
function code of a fault response message is the logical OR of 80h and the original function code of 08h. This indicates to the master that the
message is a fault response message, instead of a normal response message.
The error code indicates where the error occurred in the command message. Refer to the section Error Codes, Table 2-14, for more information
on returned error codes.

YASKAWA G7 Specifications

General

Type	DC Drive
Enclosure Rating	IP20
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Communication Interface	RS-485
Humidity	5 to 95% (non-condensing)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
