 Write Multiple Registers Normal Response Message
Table 2.12 Write Registers Normal Response Message
Description Data
Slave Address 01h
Function Code 10h
Upper 00h
Starting Register
Lower 01h
Upper 00h
Quantity
Lower 02h
Upper 10h
CRC-16
Lower 08h
The normal response message contains the same slave address, function code, starting register and quantity as the command message, indicating
to the master which slave is responding and to what type of function it is responding.
The starting register is the address of the first register written. In the response message above the starting register address is 01h (0001h).
The quantity indicates how many consecutive registers were written. In this case the quantity is 2.
 Write Multiple Registers Fault Response Message
Table 2.13 Write Registers Fault Response Message
Description Data
Slave Address 01h
Function Code 90h
Error Code 02h
Upper CDh
CRC-16
Lower C1h
The fault response message contains the same slave address as the command message, indicating to the master which slave is responding.
The function code of a fault response message is the logical OR of 80h and the original function code of 10h. This indicates to the master that
the message is a fault response message, instead of a normal response message.
The error code indicates where the error occurred in the command message. The value of 02h in the error code field of this fault response
message indicates that the command message requested data to be written to an invalid register. Refer to the section Error Codes, Table 2-14,
for more information on returned error codes.

YASKAWA G7 Specifications

General

Type	DC Drive
Enclosure Rating	IP20
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Communication Interface	RS-485
Humidity	5 to 95% (non-condensing)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
