4: Send a message from the controller to the G7 drive.
4.1: Connect an oscilloscope between the G7 drive’s R+ and R- terminals for RS-422/RS-485 4-wire networks or between
terminals R+/S+ and R-/S- for RS-485 2-wire networks.
4.1.1: Verify that the message pulse train exists and contains the correct number of pulses. Refer to the chapter
Message Formats for information on the message contents.
4.1.2: Verify that the signal levels adhere to the RS-422/RS-485 standard.
4.2: Insert a data analyzer in the RS-422/RS-485 circuit and capture the message sent by the controller in a hexadecimal
format. Record the command message below.
[
] [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ]
[
] [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ]
[
] [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ]
[
] [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ] [ ]
4.3: Verify that the contents of the message adhere to the Modbus format as described previously.
4.3.1: Verify that the node address is valid.
4.3.2: Verify that the function code is valid.
4.3.3: Verify that the register address is valid.
4.3.4: Verify that the number of data bytes is valid.
4.3.5: Verify that the CRC is correctly calculated.
4.3.6: Verify that the message requires a response.
