Table 4.13 “O” Parameters
Access Level
Name Address Description Data Range Unit Default
During
Run
V/f
V/f
w/PG
OLV FV OLV2
4 Control Method
5 Motor Speed
6 Output Voltage Reference
7 DC Bus Voltage
8 Output Power (kW)
9 Torque Reference
10 Input Terminal Status
11 Output Terminal Status
12 Internal Control Status 1
13 Elapsed Time
14 Flash ID
15 Terminal A1 Level
16 Terminal A2 Level
17 Terminal A3 Level
18 Motor Secondary Current
19 Motor Excitation Current
20 Soft Starter (SFS) Output
21 ASR Input
22 ASR Output
24 PID Feedback
25 DI-16H2 Reference
26 Voltage (Vq) Reference
27 Voltage (Vd) Reference
28 CPU ID
29 Accumulated kWh
30 Accumulated MWh
32 ACR (Iq) Output
33 ACR (Id) Output
34 OPE Detected
36 PID Input
37 PID Output
38 PID Setpoint
39 Transmit Error
40 FAN Elapsed Time
42 Estimated Motor Flux
43 Id Compensation Value
44 ASR Output Without Filter
45 Feed Forward Output
48
Stabilizing Speed at
Regeneration (OLV2)
o1-01 0500h User Monitor Selection
50 CF Error Code (OLV2)
1 6 R A A A A A
0 Frequency Reference
1 Output Frequency
2 Output Current
o1-02 0501h Power-On Monitor
3 User Monitor (o1-01)
1 1 R A A A A A
o1-03 0502h Display Scaling 0 ~ 39999 1 0 A A A A A
0 Hertz
o1-04 0503h V/F Setting Units
1 RPM
1 0 A A
o1-05 0504h LCD Contrast 0 ~ 5 1 3 A A A A A
0 Disabled
o2-01 0505h
Local / Remote Key
Selection
1 Enabled
1 1 A A A A A
0 Disabled
o2-02 0506h
Operator Stop Key
Selection
1 Enabled
1 1 A A A A
A
