77
Table 4.15 Modbus TCP/IP Interface Registers (continued)
Addr
ess
Function Bit Description
0h PUF - DC Bus Fuse Failure
1h UV1 - Main Circuit Undervoltage
2h UV2 - Control Power Undervoltage
3h UV3 - Pre-charge Contactor Answerback Failure
4h Reserved
5h GF - Ground Fault
6h OC - Overcurrent
7h OV - Overvoltage
8h OH - drive Overheat
9h OH1 - Motor Overheat Alarm
Ah OL1 - Motor Overload
Bh OL2 - drive Overload
Ch OL3 - Overtorque Detection 1
Dh OL4 - Overtorque Detection 2
Eh RR - Braking Resistor Failure
2009h Error 1
Fh RH - Braking Resistor Overheat
0h EF3 - External Fault 3
1h EF4 - External Fault 4
2h EF5 - External Fault 5
3h EF6 - External Fault 6
4h EF7 - External Fault 7
5h Reserved
6h Reserved
7h OS - Overspeed
8h DEV - Speed Deviation
9h PGO - Encoder (PG) Feedback Loss
Ah PF - Input Phase Loss
Bh LF - Output Phase Loss
Ch OH3 - Motor Overheat 1
Dh OPR - Operator Disconnected
Eh ERR - EEPROM Write Failure
200Ah Error 2
Fh OH4 - Motor Overheat 2
0h CE - Communication Loss
1h BUS - Option Card Error
2h Reserved
3h Reserved
4h CF - Loss of Motor Control
5h SVE - Zero Servo Fault
6h EF0 - Option Card External Fault
7h FBL - PID Feedback Loss
8h UL3 - Undertorque Detection 1
9h UL4 - Undertorque Detection 2
Ah OL7 - High Slip Braking Overload
Bh Reserved
Ch Reserved
Dh Reserved
Eh Reserved
200Bh Error 3
Fh CPF – Control Board Hardware Fault
200Ch
Analog Input Terminal A1
Monitor
- Keypad Monitor U1-15
200Dh Digital Input Terminal Monitor - Digital Input Terminal Value (Bit Field of Terminals S1-S8)
200Eh
Analog Input Terminal A3
Monitor
- Keypad Monitor U1-17
200Fh PG Count Channel 2 Monitor - Rolling Counter from 0 - 65,535
2010h Inverter Flash ID - Lat 5 digits of the drive software number.
