4.3 CPU Unit Specifications
System Register Specifications
4-59
4
Specifications
 Expanded Unit and Module Information
The data in these registers give hardware information about the CPU Unit and Optional Modules on Racks 1 and 5 to 7.
Name Register Addresses Remarks
CPU Unit
Information
SW13700 CPU Unit ID (Low)
SW13701 CPU Unit ID (High)
SW13702 Hardware version (BCD)
SW13703 Software version (BCD)
SW13704 Number of sub-slots (hex)
SW13705 to SW13707 Reserved for system.
SW13708 Function Module 1 ID (Low)
SW13709 Function Module 1 ID (High)
SW13710 Function Module 1 Status
SW13711 Reserved for system.
SW13712 Function Module 2 ID (Low)
SW13713 Function Module 2 ID (High)
SW13714 Function Module 2 Status
SW13715 Reserved for system.
SW13716 Function Module 3 ID (Low)
SW13717 Function Module 3 ID (High)
SW13718 Function Module 3 Status
SW13719 Reserved for system.
SW13720 Function Module 4 ID (Low)
SW13721 Function Module 4 ID (High)
SW13722 Function Module 4 Status
SW13723 Reserved for system.
SW13724 Function Module 5 ID (Low)
SW13725 Function Module 5 ID (High)
SW13726 Function Module 5 Status
SW13727 Reserved for system.
SW13728 Function Module 6 ID (Low)
SW13729 Function Module 6 ID (High)
SW13730 Function Module 6 Status
SW13731 Reserved for system.
SW13732 Function Module 7 ID (Low)
SW13733 Function Module 7 ID (High)
SW13734 Function Module 7 Status
SW13735 Reserved for system.
SW13736 Function Module 8 ID (Low)
SW13737 Function Module 8 ID (High)
SW13738 Function Module 8 Status
SW13739 Reserved for system.
SW13740 Function Module 9 ID (Low)
SW13741 Function Module 9 ID (High)
SW13742 Function Module 9 Status
SW13743 Reserved for system.
SW13744 Function Module 10 ID (Low)
SW13745 Function Module 10 ID (High)
SW13746 Function Module 10 Status
SW13747 Reserved for system.
Continued on next page.
