4.3 CPU Unit Specifications
System Register Specifications
4-60
Unit and Optional
Module Informa-
tion
SW13748
Rack 1
Unit 1
Slot 1
Optional Unit and Module
ID (Low)
SW13749
Optional Unit and Module
ID (High)
SW13750 Hardware version (BCD)
SW13751 Software version (BCD)
SW13752 Number of sub-slots (hex)
SW13753 to SW13755 Reserved for system.
SW13756
Function Module 1 ID
(Low)
SW13757
Function Module 1 ID
(High)
SW13758 Function Module 1 Status
SW13759 Reserved for system.
SW13760
Function Module 2 ID
(Low)
SW13761
Function Module 2 ID
(High)
SW13762 Function Module 2 Status
SW13763 Reserved for system.
SW13764 to SW13779 Slot 2
Same as above.
SW13780 to SW13795 Slot 3
SW13796 to SW13811 Slot 4
SW13812 to SW13827 Slot 5
SW13828 to SW13843 Slot 6
SW13844 to SW13859 Slot 7
SW13860 to SW13875 Slot 8
SW13876 to SW13891
Unit 2
Slot 1
SW13892 to SW13907 Slot 2
SW13908 to SW13923 Slot 3
SW13924 to SW13939 Slot 4
SW13940 to SW13955 Slot 5
SW13956 to SW13971 Slot 6
SW13972 to SW13987 Slot 7
SW13988 to SW14003 Slot 8
SW14004 to SW14019
Unit 3
Slot 1
SW14020 to SW14035 Slot 2
SW14036 to SW14051 Slot 3
SW14052 to SW14067 Slot 4
SW14068 to SW14083 Slot 5
SW14084 to SW14099 Slot 6
SW14100 to SW14115 Slot 7
SW14116 to SW14131 Slot 8
Continued on next page.
Continued from previous page.
Name Register Addresses Remarks
