1.3 Devices and Components That Are Required to Build a System
1-10
MECHATROLINK-
III Cable
Connects the CPU Unit
to MECHATROLINK-III
Communications devices.
JEPMC-W6012-
-E
Standard cable
Length: 0.2 to 50 m
JEPMC-W6013-
-E
Cable with ferrite cores
Length: 10 to 50 m
JEPMC-W6014-
-E
Cable with loose wires at one end
Length: 0.5 to 50 m
SERVOPACK with
MECHATROLINK-
III Communications
Used to control Servomo-
tors.
SGDV-
21
Σ-V-series AC SERVOPACK with MECHA-
TROLINK-III Communications for Rota-
tional Motor
SGDV-
25
Σ-V-series AC SERVOPACK with MECHA-
TROLINK-III Communications for Linear
Motor
I/O Modules with MECHATROLINK-III Communications
64-point I/O
Module
Used to input or output
digital, analog, or pulse
train signals.
JEPMC-MTD2310-E 24 VDC, 64 inputs, 64 outputs
Analog Input
Module
JEPMC-MTA2900-E 8 analog input channels
Analog Output
Module
JEPMC-MTA2910-E 4 analog output channels
Pulse Train Input
Module
JEPMC-MTP2900-E 2 pulse-train inputs
Pulse Train Out-
put Module
JEPMC-MTP2910-E 4 pulse-train outputs
MPE720 Integrated
Engineering Tool
Ver si o n 7
Used to adjust, maintain,
and program AC Servo
Drives and Inverters that
are connected to the net-
work.
CPMC-MPE780 −
Rack Expansion
Interface Unit Cable
Used to use a Rack
Expansion Interface Unit
to connect the Main Rack
to an Expansion Rack.
JEPMC-W3401-A5-E Length: 0.5 m
• Connector on both ends
with ferrite cores
• Wire size: AWG28
• Twin coaxial cable
JEPMC-W3401-2A5-E Length: 2.5 m
JEPMC-W3401-06-E Length: 6.0 m
EXIOIF Module
Cable*
Used to use an EXIOIF
Module to connect the
Main Rack to an Expan-
sion Rack or to connect
two Expansion Racks.
JEPMC-W2094-A5-E Length: 0.5 m
• If you use more than one
Cable, do not allow the
total cable length to
exceed 6 m.
• Connector on both ends
with ferrite cores
• Wire size: AWG28
• Equivalent to UL20276.
JEPMC-W2094-01-E Length: 1.0 m
JEPMC-W2094-2A5-E Length: 2.5 m
Continued on next page.
Continued from previous page.
No. Name Use Model Remarks
