3.2 Function Modules
Self Configuration
3-42
Self Configuration Using the MPE720
There are two types of self configuration that can be performed with the MPE720.
• Self configuration of all Modules: Use this mode when the system is being set up for the first time, or
after the entire system has been changed.
• Self configuration of specified Modules: Use this mode when a part of the system has been changed.
This process will automatically recognize all devices that have been added or removed, and automati-
cally generate definition files for them.
Self Configuration of All Modules
1.
Click the Module Configuration Icon on the Start Tab Page.
The following Module Configuration Definition Tab Page will be displayed.
Before performing this procedure, turn ON the power supply to the SERVOPACKs and other devices.
To Next Page
