B Parameter Table
188 YASKAWA ELECTRIC TOEP C710616 38H YASKAWA AC Drive-L1000A Quick Start Guide
■ H4: Analog Outputs
No. Name Description Setting
H4-01
Terminal FM Monitor
Selection
Selects the data to be output through multi-function analog output terminal FM.
Set the desired monitor parameter to the digits available in U-. For example,
enter “103” for U1-03.
Default: 102
Min: 000
Max: 999
H4-02
Terminal FM Gain
Sets the signal level at terminal FM that is equal to 100% of the selected monitor
value.
Default: 100.0%
Min: -999.9%
Max: 999.9%
H4-03
Terminal FM Bias Sets the bias value added to the terminal FM output signal.
Default: 0.0%
Min: -999.9%
Max: 999.9%
H4-04
Terminal AM Monitor
Selection
Selects the data to be output through multi-function analog output terminal AM.
Set the desired monitor parameter to the digits available in U-. For example,
enter “103” for U1-03.
Default: 103
Min: 000
Max: 999
H4-05
Terminal AM Gain
Sets the signal level at terminal AM that is equal to 100% of the selected monitor
value.
Default: 50.0%
Min: -999.9%
Max: 999.9%
H4-06
Terminal AM Bias Sets the bias value added to the terminal AM output signal.
Default: 0.0%
Min: -999.9%
Max: 999.9%
H4-07
Terminal FM Signal Level
Selection
0: 0 to 10 V
1: -10 to 10 V
Default: 0
Min: 0
Max: 1
H4-08
Terminal AM Signal Level
Selection
0: 0 to 10 V
1: -10 to 10 V
Default: 0
Min: 0
Max: 1
