Maintenance and inspection
9
- 72
If the "OUT OF RANGE (ABSO DA-
TA)" alarm occurs:
Compare second home position
(check point)* pulses with current po-
sition pulses.
alarm reset Alarm occurs again
SERVO-ON power ON Correct the faulty axis, replace the
pulse generator system, set the home
position
Procedure after alarm * Position checking point
Position confirmation operation Automatic mode possible
OK
NOK
