Wire Gauge Terminal Screws
Crimp Terminal
Model Number
Tool
Insulation Cap
Model No.
Code
Machine No. Die Jaw
250 / 300 kcmil
M10 R150-10
YF-1, YET-150-1
YF-1, YET-300-1
TD-229, TD-215
TD-325, TD-313
TP-150 100-051-272
M12 R150-12
YF-1, YET-150-1
YF-1, YET-300-1
TD-229, TD-215
TD-325, TD-313
TP-150 100-051-273
250 kcmil × 2P
250 kcmil × 4P
300 kcmil × 2P
300 kcmil × 4P
M10 150-L10
YF-1, YET-150-1
YF-1, YET-300-1
TD-229, TD-215
TD-325, TD-313
TP-150 100-051-561
M12 150-L12
YF-1, YET-150-1
YF-1, YET-300-1
TD-229, TD-215
TD-325, TD-313
TP-150 100-051-562
350 kcmil
M10 180-10 YF-1, YET-300-1 TD-326, TD-313 TP-200 100-066-687
M12 180-12 YF-1, YET-300-1 TD-326, TD-313 TP-200 100-066-689
400 kcmil
M10 200-10 YF-1, YET-300-1 TD-327, TD-314 TP-200 100-051-563
M12 R200-12 YF-1, YET-300-1 TD-327, TD-314 TP-200 100-051-275
350 kcmil × 2P M12 180-L12 YF-1, YET-300-1 TD-326, TD-313 TP-200 100-066-688
400 kcmil × 2P M12 200-L12 YF-1, YET-300-1 TD-327, TD-314 TP-200 100-051-564
500 kcmil
600 / 650 kcmil
500 kcmil × 2P
600 kcmil × 2P
M10 325-10 YF-1, YET-300-1 TD-328, TD-315 TP-325 100-051-565
M12 325-12 YF-1, YET-300-1 TD-328, TD-315 TP-325 100-051-277
<1> Codes refer to a set of three crimp terminals and three insulation caps. Prepare input and output wiring using two sets for each connection.
Example 1: Models with 300 kcmil for both input and output require one set for input terminals and one set for output terminals, so the user should
order two sets of [100-051-272].
Example 2: Models with 4/0 AWG × 2P for both input and output require two sets for input terminals and two sets for output terminals, so the user
should order four sets of [100-051-560].
10 Standards Compliance
88
YASKAWA TOEP YAIP1U 04A YASKAWA AC Drive – P1000 6-Phase/12-Pulse Input Installation Manual
