YASKAWA P1000 Series User Manual

Closed-Loop Crimp Terminal Recommendations
Yaskawa recommends using closed-loop crimp terminals on all drive models. UL approval requires the use of UL Listed crimp
terminals when wiring the drive main circuit terminals. Use only crimping tools as specified by the crimp terminal
manufacturer. Yaskawa recommends crimp terminals made by JST and Tokyo DIP (or equivalent) for the insulation cap.
Table 15matches the wire gauges and terminal screw sizes with Yaskawa-recommended crimp terminals, tools, and insulation
caps. Refer to Wire Gauge and Torque Specifications on page 25 for the wire gauge and screw size for your drive model.
Place orders with a Yaskawa representative or the Yaskawa sales department.
The closed-loop crimp terminal sizes and values listed in Table 15 are Yaskawa recommendations. Refer to local codes for
proper selections.
Table 15 Closed-Loop Crimp Terminal Size
Wire Gauge Terminal Screws
Crimp Terminal
Model Number
Tool
Insulation Cap
Model No.
Code
Machine No. Die Jaw
14 AWG M4 R2-4 YA-4 AD-900 TP-003 100-054-028
12 / 10 AWG
M4 R5.5-4 YA-4 AD-900 TP-005 100-054-029
M5 R5.5-5 YA-4 AD-900 TP-005 100-054-030
M6 R5.5-6 YA-4 AD-900 TP-005 100-068-029
M8 R5.5-8 YA-4 AD-900 TP-005 100-068-030
8 AWG
M4 8-4 YA-4 AD-901 TP-008 100-054-031
M5 R8-5 YA-4 AD-901 TP-008 100-054-032
M8 R8-8 YA-4 AD-901 TP-008 100-061-111
6 AWG
M4 14-NK4 YA-4, YA-5 AD-902, AD-952 TP-014 100-054-033
M5 R14-5 YA-4, YA-5 AD-902, AD-952 TP-014 100-054-034
M6 R14-6 YA-4, YA-5 AD-902, AD-952 TP-014 100-051-261
M8 R14-8 YA-4, YA-5 AD-902, AD-952 TP-014 100-054-035
M10 R14-10 YA-4, YA-5 AD-902, AD-952 TP-014 100-061-112
4 AWG
M6 R22-6 YA-5 AD-953 TP-022 100-051-262
M8 R22-8 YA-5 AD-953 TP-022 100-051-263
M10 R22-10 YA-5 AD-953 TP-022 100-061-113
3 / 2 / 1 AWG
M6 38-S6 YA-5 AD-954 TP-038 100-068-031
M8 R38-8 YA-5 AD-954 TP-038 100-051-264
M10 R38-10 YA-5 AD-954 TP-038 100-061-114
1/0 AWG
1/0 AWG × 2P
M8 R60-8
YA-5
YF-1, YET-300-1
AD-955
TD-321, TD-311
TP-060 100-051-265
M10 R60-10
YA-5
YF-1, YET-300-1
AD-955
TD-321, TD-311
TP-060 100-051-266
1 AWG × 2P
2 AWG × 2P
M10 38-L10
YA-5
YF-1, YET-150-1
AD-954
TD-224, TD-212
TP-038 100-051-556
2/0 AWG
2/0 AWG × 2P
M10 70-10 YF-1, YET-300-1 TD-323, TD-312 TP-080 100-054-036
3/0 AWG M10 80-10 YF-1, YET-300-1 TD-323, TD-312 TP-080 100-051-267
3/0 AWG × 2P 3/0
AWG × 4P
M10 80-L10
YF-1, YET-150-1
YF-1, YET-300-1
TD-227, TD-214
TD-323, TD-312
TP-080 100-051-557
M12 80-L12
YF-1, YET-150-1
YF-1, YET-300-1
TD-227, TD-214
TD-323, TD-312
TP-080 100-051-558
4/0 AWG
M8 100-8
YF-1, YET-150-1
YF-1, YET-300-1
TD-228, TD-214
TD-324, TD-312
TP-100 100-068-032
M10 R100-10
YF-1, YET-150-1
YF-1, YET-300-1
TD-228, TD-214
TD-324, TD-312
TP-100 100-051-269
4/0 AWG × 2P
4/0 AWG × 4P
M10 100-L10
YF-1, YET-150-1
YF-1, YET-300-1
TD-228, TD-214
TD-324, TD-312
TP-100 100-051-559
M12 100-L12
YF-1, YET-150-1
YF-1, YET-300-1
TD-228, TD-214
TD-324, TD-312
TP-100 100-051-560
10 Standards Compliance
YASKAWA TOEP YAIP1U 04A YASKAWA AC Drive – P1000 6-Phase/12-Pulse Input Installation Manual
87

YASKAWA P1000 Series Specifications

General

Series	P1000
Voltage Classes	200 V, 400 V, 600 V
Frequency	50/60 Hz
Humidity	95% RH or less (non-condensing)
Type	AC Drive
Control Method	V/f Control
Ambient Temperature	-10 to +50°C (14 to 122°F)
Communication Options	Modbus RTU
Protection Features	Overvoltage, Undervoltage
Overload Capacity	150% for 60 seconds
Storage Temperature	-20°C to +60°C (-4 to 140°F)
Cooling Method	Fan cooled
Horsepower Range	0.5 to 500 HP
